Sale!

TYT TC-3000A 10W Walkie Talkie with 3600mAh Battery Voice Encryption Two Way Radio

$69.80

9 in stock

SKU: 32728904408 Categories: , Tags: , , ,

Description

Most Powerful TYT 10W Max Walkie Talkie TC-3000A with 3600MAH Battery Voice Encryption Two Way Radio



All of our items are brand News

Model

TC-3000A

Frequency Range

UHF:400-520MHz

Channel capacity

16

Max Output power

High:10W/Low:5W

Operating Voltage

7.2V DC

Antenna Impedance

50 ohm

Working Temperature

-20°C—+50°C

Frequency Spacing

12.5kHz/25kHz

Max Battery capacity

3600mAh

Color

Black

Dimension(Exclude antenna)

133x59x36mm

Weight(Include Battery)

272g

Feature

3600mAh polymer Li-ion Battery

Yes

260 hours long standby time

Yes

CTCSS/DCS non-standby code

Yes

High/Low power selectable

Yes

English/Chinese Voice prompt

Yes

VOX sensitivity adjustable

Yes

10W/5W power switch with side-key operation

Yes

10 Watt ultra-high output power

Yes

High/Low voltage TX selection

Yes

PC program protection

Yes

COMP/Scrambler

Yes

Voice companding function

Yes

Bandwidth selectable(12.5/25kHz

Yes

Battery save function

Yes

1750Hz tone

Yes

Squelch adjustment function

Yes

End-tone elimination

Yes

Receiving alarm

Yes

Time-out-timer(TOT)

Yes

Side-key assignment

Yes

Low-battery alert

Yes

Busy channel lock

Yes

VOX transmitting

Yes

Scanning

Yes

Specification

Working mode

Simplex or semi-duplex

Modulation type

16KF¢3E

Spurious radiation

<=7.5µW

Modulated noise

<-40dB

Modulation distortion

<55

Frequency stability

5ppm

Max Fr. Deviation

<=±5kHz

Current

<=2600mA

Audio response

+6.5—14dB

Adjacent Ch. Power

>=65dB

Intermediation sensitivity

8-12mv

Receiver

Sensitivity

<=0.2V

Occupied bandwidth

<=16kHz

Selectivity

>=65dB

intermediation

>=55dB

Audio power

1W

Audio distortion

<=5%

Frequency stability

5ppm

Curent

80mA(when standby)
220mA(when working)

Audio response

+7—12.5dB





 TC-3000A-1-1



 TC-3000A-4-1

 TC-3000A-6-1



 TC-3000A-7-1









 TC-3000A-8-1
