Talinfone W5 Zello Walkie Talkie UHF 400-470MHz 3G Android 6.0 GSM WCDMA Phone

W5 Shockproof Zello Phone Walkie Talkie 20KM IP67 Waterproof Phone 5000mah Battery 5MP Camera Android 6 smartphone

Support Zello Platform Communication

Unlock Phones: Yes

Google Play: Yes

Cellular: GSM/WCDMA

Rear Camera: 2MP



Feature:

Waterproof, Dustproof, Touchscreen, FM Radio, GPS Navigation, Wi-Fi, Memory Card Slots



CPU: Quad Core

Operation System: Android

Front Camera: 5MP

RAM: 1G

Display Resolution: 854×480

Battery Capacity(mAh): 5000

Design: Bar

Language: Russian, Italian, German, French, Spanish, Polish, Portuguese, English

Camera Type: Front & Back Camera

SIM Card Quantity: Dual SIM Cards

ROM: 8G

Release Date: 2017

Touch Screen Type: Capacitive Screen

Talk Time: 10

Item Condition: New

Brand Name: Rungee

CPU Manufacturer: MTK

Band Mode: 2SIM/Multi-Bands

Battery Type: Detachable

Display Color: Color

Size: 140*65*30MM

Display Size: 3.5

Thickness: Normal(>10mm)

Language: Chinese , English , German , Spanish , Portuguese , French over 50 country and so on.



HW SPEC

CPU	MT6580 1.3GHz
System	Android 6.0
Frequency range	400-470MHZ
Memory	1GB+8GB DDR3 SD Card 32GB(Max)(3GB+32GB Option)
Display	3.5inch 854*480
Touch screen	3.5,capacitance
Camera	Rear 5MP,Front 2MP
Battery	5000mAh,detachable
Size	140*65*30MM
Quality	300g
Volume	140MM*65MM*30MM
Waterproofing grade	IP67



Operating temperature	-10—+55℃
Storage temperature range	-40—+85℃



GSM	B2 B3 B5 B8
WCDMA	B1 B2 B5 B8



GPS Support	Yes
Wifi/FM	Yes

Talinfone W460 IP67 Waterproof Walkie Talkie Hiden Display Two Way Radio

IP-68 Technical parameters of waterproof interphone

Technical parameters of waterproof radio

Specification of the packaging color box: 220mm* l 60mm*85mm

Optional frequency range

1, Integrated PCB: 10W 400-480MHZ

2. Traditional PCB: 10W 136- 174MHZ

3. Traditional PCB: 10W 400-480MHZ

Number of channels: 128

Channel Space 25KHZ 112.5KHZ

Working voltage 7.5V +/- 10%

Battery capacity: Lithium battery 3000MAH

Working temperature: – -30– -60

Antenna impedance: 509

Standby current 10 50MA

Dimensions: 130 * 60 * 39mm

Weight: 300g (include battery & antenna)

Waterproof rating: IP67

Transmitter :

Frequency stability:+/-2.5ppm

Output power: 10W+/-0.5W

Modulation limitation < 5Khz, Narrow < 2.5Khz

Audio distortion < 5%

Transmit Current < 2.6- -2.65A

Modulaiton characteristics :_ +-3dB

Adjacent Channel Power > 65dB

Spurious Emission: < 65uW

Occupied bandwidth < 16KHZ

RECEIVER

Receive Sensitivity: 12dB(SINAD> 0.2uV

Audio output power: 1w

Audio distortion < 5%

Audio response: +- -3dB

CoChannel suppression > 8dB

Adjacent Channel selective > 55dB

Intermodulation immunity > 55dB

Spurious response immunity > 55dB

Blocking characteristics > 84dB

Talinfone GT-10F UHF VHF Active View Display Two Way Radio 10 Watts Handheld Walkie Talkie

Product Features

Active View Display

Output Power:  10 W(H)  5W(M)  2W(L)

Battery Capacity: 3000mAh

(Li-polymer  battery)

Hidden LCD Display

Scan Function

VOX Function

Wide/Narrow Band 25KHz/12.5KHz

Emergency Alarm

Battery Saver

Low Battery Warning

Scrambler Function

Channel Lock Out

TOT Function

CTCSS/DCS

Squelch Level Adjust

Technical Specifications

General
Frequency Range	UHF 400-470MHz
VHF 136-174MHz
Channel Capacity	199CH
Channel Spacing	12.5KHz/25KHz
Operating Voltage	7.4V-8.4V DC
Battery Capacity	3000mAh (Li-polymer)
Operating Temperature	-20℃ to +50 ℃
Frequency Stability	±2.5ppm
Antenna Impedance	50Ω
Dimension	65x46x140mm

Transmitter
Output Power	H:10Watts  M: 5Watts  L:2watts
Modulation Type	16kφF3E(Wide Band)
11kφF3E(Narrow Band)
MAX. Frequency Deviation	<5KHZ(Wind Band)
<2.5KHZ(Narrow Band)
Adjacent Channel Power	≥60dBTransmitter
S/N	≥45dB
Audio Distortion	≤3%
Audio Response	6dB/Each octave
FM	≤-36dB

Receiver
Sensitivity(12dB SINAD)	≤0.25uV(Wide Band)
≤0.35uV(Narrow Band)
Intermodulation	65dB
Adjacent Channel Selectivity	≥65dB(Wide Band) ≥60dB(Narrow Band)
S/N	≥50dB
Audio Response	6dB/Each octave
Rated Audio Distortion	≤3%
Audio Output Level	22dBMW(10%hours)
Rated Audio Output power	1000mw
Spurious Rejection	≥80dB
MAX. Frequency Deviation	<5KHZ(Wind Band)  <2.5KHZ(Narrow Band)

Each Unit Package Included:

1 X Talinfone GT-10F VHF/UHF Transceiver

1 X 8.4V 3000mAh Li-polymer Battery

1 X 14.5cm Antenna

1 X 37.5cm Antenna

1 X Belt Clip

1 X Charger Docking

1 X 100-240V AC Power

1 X Hand Strap

1 X User’s Manual
